DHE instantaneous water heater - an unfailing guarantee of hot water at exactly the right temperature.
The fully electronic DHE instantaneous water heater provides hot water at the exact temperature you have set - every time. 4i technology guarantees that any factors which would change the outlet temperature are compensated for. This way you can enjoy a shower in comfort, even when someone is washing their hands at the adjacent washbasin.

Top-quality in operation too.
Due to the special haptic rotary selector, the appliance is very easy to operate: settings and adjustments are intuitive and take very little time. The set water temperature, ECO level and current power consumption can be seen clearly and concisely on the illuminated multifunction display. Energy consumption, flow rate, time, status and service display can be checked in the lower area.

Technical Data

• Height: 466mm
• Width: 225mm
• Depth: 116mm
• Weight (filled with water): 3.2kg
• Colour: white
• Nominal capacity: 0.4L
• Approvals: WaterMark Lic No. WMKA00301, AS3498
• For one/several draw off points: Yes/Yes
• Heating system: Bare wire
• Electronic flow rate control: Yes
• Electronic air detection system: Yes
• Accepts pre-heated water (solar): Yes (incoming hot water must not exceed 55°C)
• Programmable temperature: Yes

• Rated output (415V): 19.4kW
• Rated current (415V): 27Amp
• Phases: 3/PE
• Electrical installation: As per AS/NZS3000
• Installation requirements: AS/NZS3500.4.2 & local requirements
• Switch on flow rate (minimum flow rate required to switch on the water heater): 2.5L/min
• Max. permissible pressure: 1 MPa
• Temperature adjustment: 20-60°C
• IP Rating: IP25
